SMD 2835 Series

LED Strip light 2835-120D-8MM-24v IP20-IP65-IP66-IP67-IP68

LED Strip with wide beam angle and high output lumen.So,it is wonderfully suitable for uniform linear lighting of every room.
Even for those who want to let their creativity run wild with strips,our LED Strip is suitable as well.
High color rendering and high flexibility give you a plenty of scope and bring art to your wall with light.
Simply bend the LED Strip into the desired shape and attach it to your wall with accessories.

LED Strip light 2835-120D-8MM-24v IP20-IP65-IP66-IP67-IP68PRICE QUOTING
Home Product SMD 2835 Series

Specifications

(1).High quality and high brightness SMD LED chip.
(2).Variety of monochromatic lights for option including Red,Green,Blue,Yellow,Pink,Orange,Violet and whitelight.
(3).Flat profile,good choice for recessed mounting.
(4).Environmentally friendly&energy efficient.
(5).High color consistency.
(6).Perfect softness,gentle emitting,Not dazzling.
(7).3-5 years warranty.
LED Strip light 2835-120D-8MM-24v IP20-IP65-IP66-IP67-IP68 Technical Specifications

LED Strip light 2835-120D-8MM-24v IP20-IP65-IP66-IP67-IP68

IP20 8*1.4 IP65 8*2.6 IP66 10.5*4 IP67 9.8*3.8 IP68 10.5*4.6
Model No. CCT Lumens
（lm/M）
±10% 		Weight
（g/Roll） 		Lumens
（lm/M）
±10% 		Weight
（g/Roll） 		Lumens
（lm/M）
±10% 		Weight
（g/Roll） 		Lumens
（lm/M）
±10% 		Weight
（g/Roll） 		Lumens
（lm/M）
±10% 		Weight
（g/Roll）
**-C27120C 2700K 1050 135 970 220 900 295 1050 272 1050 390
**-C30120C 3000K 1085 135 1000 220 930 295 1085 272 1085 390
**-C40120C 4000K 1110 135 1030 220 955 295 1110 272 1110 390
**-C50120C 5000K 1150 135 1070 220 990 295 1150 272 1150 390
**-C65120C 6500K 1180 135 1100 220 1010 295 1180 272 1180 390
**-CRE120C Red 240 135 223 220 206 295 223 272 223 390
**-CGR120C Green 400 135 372 220 344 295 372 272 372 390
**-CBL120C Blue 200 135 186 220 172 295 186 272 186 390
**-CYE120C Yellow 362 135 337 220 311 295 337 272 337 390
**-CPI120C Pink 298 135 277 220 256 295 277 272 277 390
**-CUV120C Purple 9.2 135 8.6 220 7.9 295 8.6 272 8.6 390
**-COR120C Orange 900 135 837 220 774 295 837 272 837 390

Specification Data
